Customized Size Glossy / Matt Lamination Roll , Plastic Clear Laminate Roll

Brand Name : AFP

Model Number : Roll Lamination Film

Certification : SGS, BV,

Place of Origin : Fujian, China

MOQ : 1 Ton (1,000kgs)/Trial Order Negotiable

Price : USD2188.00/Ton ~ USD2370.00/Ton

Payment Terms : T/T, L/C, Western Union

Supply Ability : 850 Tons per month

Delivery Time : 15 - 25 working days a 40GP

Packaging Details : 1-One roll one carton with plastic caps protection; 2-Tens of rolls a pallet; 3-Twenty pallets a 20FCL

Material : BOPP + EVA

Type : Roll Lamination Film

Softness : Soft

Thickness : 15micron, 18micron, 21micron, 24micron, 26micron etc.

Transparency : Transparent

Roll Size : 445mm*3000m, 630mm*3000m

Corona Treatment : Double sides, over 38 dynes

Paper Core : 1 inch (25.4mm), 3"(76mm)

Processing Technology : Multiple Extrusion

Usage : Printed Paperboard or Paper Laminate, Shopping Bag Laminate

Contact Now

Customized Size Glossy / Matt Lamination Roll, Plastic Clear Laminate Roll

Product Overview

Clear transparent plastic roll lamination film available in glossy or matte finish, used for dry thermal lamination with paper or paperboard using various laminator machines. Made with BOPP base film and EVA adhesive glue that melts during the laminating process. Customized roll sizes available, such as 445mm*3000m, 630mm*3000m, etc.

Customized Size Glossy / Matt Lamination Roll , Plastic Clear Laminate Roll

What is BOPP Thermal Lamination Film?

BOPP Thermal Laminating Film is primarily composed of BOPP + EVA layers combined through extrusion coating process. One side features BOPP film properties while the other side provides heat-sensitive surface for dry lamination. Available in glossy/shine/transparent and matte/opaque finishes with thickness ranging from 14micron to 32micron. Width options from 180mm to 1880mm and length from 150m (1 inch core, 25mm) to 4000m (3 inch core, 76mm).

Applications

Textbook covers
Brochures
Leaflets
Sweet boxes
Cosmetics packaging
Shopping bags
Diaries

How to Use BOPP Thermal Lamination Film

Requires a laminating machine (hot laminator) to melt EVA adhesive onto substrates like paper. The film passes over a heated roller and adheres to paper under appropriate pressure. This easy process can be performed at home for small applications. Also known as heat lamination, dry lamination, or hot lamination.

Operation Guidance

Adjust roller pressure and temperature according to paper and ink types
Conduct small trial volume when using film for first time or changing sizes
Normal process temperature: 90°C-105°C (203°F - 221°F)
Ensure ink is completely dry before laminating
Store materials in low temperature, dry environments

Quality may be affected by: metal ink, ink with excessive wax/dried oil/adhesive/silicon additives, overly thick ink, undried ink, humid paper, or excessive surface powder.

Product Specifications

Specification	AFP-L18 Glossy	AFP-L21 Glossy	AFP-L25 Glossy	AFP-L25 Glossy	AFP-Y20 Matte	AFP-Y25 Matte	AFP-Y27 Matte
Thickness (BOPP)	12 micron	12 micron	12 micron	15 micron	12 micron	15 micron	15 micron
Thickness (EVA)	6 micron	9 micron	13 micron	10 micron	8 micron	10 micron	12 micron
Total Thickness	18 micron	21 micron	25 micron	25 micron	20 micron	25 micron	27 micron
Yield (m²/kg)	61.275	52.247	43.668	43.956	56.433	45.147	41.615
kg/m²	0.0163	0.0191	0.0229	0.0228	0.0177	0.0222	0.0240

Customized thickness combinations available (15 micron to 30 micron, glossy and matte). Pricing available by metric ton or square meter.

Sample Order Configuration

Glossy 22micron (12BOPP+10EVA)

350mm(13.8") x 3000m(9843') x 30rolls (weight 654.60kgs = 21.82kgs x 30rolls, square meter 31,500m²)

445mm(17.5") x 3000m(9843') x 20rolls (weight 554.80kgs = 27.74kgs x 20rolls, square meter 26,700m²)

Matte 25micron (15BOPP+10EVA)

350mm(13.8") x 3000m(9843') x 30rolls (weight 719.70kgs = 23.99kgs x 30rolls, square meter 31,500m²)

445mm(17.5") x 3000m(9843') x 20rolls (weight 610.00kgs = 30.50kgs x 20rolls, square meter 26,700m²)

Total: 100 rolls, weight 2,539.10kgs, square meter 116,400m²

Popular Specifications & Roll Weights

Measure	Type	18 micron (12 BOPP+6EVA)	22 micron (12 BOPP+10 EVA)	25 micron (12 BOPP+13 EVA)	25 micron (15 BOPP+10 EVA)
350mm x 3000m	Glossy/Shine	17.87 kgs/roll	21.82 kgs/roll	24.78 kgs/roll	24.62 kgs/roll
350mm x 3000m	Matte/Dull	17.37 kgs/roll	21.31 kgs/roll	24.27 kgs/roll	23.99 kgs/roll
445mm x 3000m	Glossy/Shine	22.72 kgs/roll	27.74 kgs/roll	31.50 kgs/roll	31.30 kgs/roll
445mm x 3000m	Matte/Dull	22.08 kgs/roll	27.10 kgs/roll	30.86 kgs/roll	30.50 kgs/roll
500mm x 3000m	Glossy/Shine	25.53 kgs/roll	31.17 kgs/roll	35.40 kgs/roll	35.17 kgs/roll
500mm x 3000m	Matte/Dull	24.81 kgs/roll	30.45 kgs/roll	34.68 kgs/roll	34.27 kgs/roll
600mm x 3000m	Glossy/Shine	30.63 kgs/roll	37.40 kgs/roll	42.48 kgs/roll	42.21 kgs/roll
600mm x 3000m	Matte/Dull	29.77 kgs/roll	36.54 kgs/roll	41.61 kgs/roll	41.13 kgs/roll
700mm x 3000m	Glossy/Shine	34.73 kgs/roll	43.64 kgs/roll	49.56 kgs/roll	49.24 kgs/roll
700mm x 3000m	Matte/Dull	42.63 kgs/roll	42.63 kgs/roll	48.55 kgs/roll	47.98 kgs/roll

Key Features

#1 Healthy Lamination Process

Non-hazardous and safe to use with no toxic gases or volatile content. Safe during laminating process due to solvent-free adhesive.

#2 Easy Operation

No rubber, solvent, or diluent mixing required. Easy handling and cost-effective compared to traditional methods. No special techniques needed.

#3 High Efficiency and Energy-saving

Substantially reduced production cost with no film wastage, no adhesive mixing, no coating/drying processes, and no UV heating lamp required.

#4 Outstanding Function and Effect

High transparency and superior luster finish enhance product value. Protection against pressing, bubbling, and delamination. Water-proof and long-lasting storage protection. Matte finish suitable for UV varnishing and hot stamping.

Shipping & Packaging

One roll per carton
Tens of rolls per pallet
10-12 pallets per 20ft container (approx. 13MT)
20-22 pallets per 40ft container (approx. 25MT)
Seaports: Xiamen, Shanghai, Ningbo
Airbags used for pallet protection during container loading

Quality Assurance

Strict quality management principles with careful control over every processing detail. Compensation provided for any defective rolls found.

Quality Comparison

Frequently Asked Questions

About Samples

Samples available for testing free of charge
Standard sizes: 300/400mm x 100m/200m per glossy or matte roll
Custom measurements available upon request
Freight costs borne by receiver but refunded from subsequent orders
Prepaid shipping recommended for cost savings

Production Capacity

5 coating lines
20-day delivery for 40ft container
850MT per month production capacity
Thickness: 15micron (10BOPP+5EVA) to 32micron (18BOPP+14EVA)
Roll width: 180mm to 1680mm
Roll length: 2000m to 6000m
Reel inner diameter: 25.4mm (1 inch) or 76mm (3 inch)
Reel outer diameter: 240mm to 380mm
